Chapter 2: ML410 Embedded Development Platform
R
All signals with length matching requirements, MGT and LVDS pairs, must include an
offset to account for the Z-Dok+ propagation delays. The ML410 platforms account for
one-half of the offset, while a user-designed adapter board must account for the other half.
The relative offsets for the ML410 host board PM connector are included in Table 2-46 .
Users are required to compensate for these offsets when designing adapter boards.
Table 2-46:
Relative Offsets from the FPGA to the PM1 and PM2 Connectors
ZDOK+ Connector
Row A
Row C
Row D
Row F
Difference
F – A = 1513 – 830
F – C = 1513 – 1125
F – D = 1513 – 1219
F–F=0–0
Offset
683
389
294
0
Offset/2 (1)
342
194
147
0
Notes:
1. All offsets are normalized to row F. The ML410 design is based on the data in the Offset/2 column.
PM1 Connector
The PM1 connector provides the following signals:
?
?
?
?
?
?
?
8 RocketIO 3.125 Gb/s transceivers
3 LVDS pairs at 2.5V (can be used as 6 single-ended I/O at 2.5V)
1 LVDS clock pair at 2.5V
12 single- ended I/O at 2.5V
26 single-ended I/O at 3.3V
1 single-ended clock at 2.5V
1 pin not connected
PM2 Connector
The PM2 connector on provides the following signals:
?
?
?
39 LVDS pairs at 2.5V (can be used as 78 single-ended I/O at 2.5V)
1 single-ended clock at 2.5V
1 pin not connected
Adapter Board PM Connectors
Tyco Z-Dok+ adapter board connectors (part number 1367555-1) are the receptacle
connectors on the personality modules that mate to the ML410 host board connectors. See
the 1367555-1 data sheet at Tyco’s website (www.z-dok.com).
On the adapter board connectors, located on the personality module, each signal pair has
a pair of ground pins on the opposite side of the open space, as shown in Figure 2-27,
page 87 . The signal pairs alternate from side to side along the length of the open space. All
of the B and E pins are two contacts tied together and grounded on the personality module.
The A, C, D, and F pins are signal pins.
86
www.xilinx.com
ML410 Embedded Development Platform
UG085 (v1.7.2) December 11, 2008
